I didn’t get as far on the framing as I would have liked this weekend…with Mike’s help I got the front beam for the porch built, the piers set and filled with concrete…and the old bodarc pilings removed.

The heat caught up with me at that point…although I didn’t realize it had gotten that hot the heat index had gone to 109.

First, we pulled the old bodarc piers.

Genuine ur...decorative antique pilings anybody?

Genuine ur…decorative antique pilings anybody?

Bodarc (also called Osage Orange, Post Oak, or Horseapple trees around these parts) is a very hard wood that is practically impervious to bugs and rot. It was used as pilings for raised building construction all over the south from the 1800’s to about 1960.

Most of these were still in good condition but one was slightly hollow and the termites were using it as an elevator to attack the porch lumber.

I could have reused them, I will add a termite barrier (essentially cap them with a piece of flashing) to any I work on under the house, but I needed to move them around for better framing and structural support for the porch so I figured I’d just replace them.

Here’s one shown for size. This weighs in at about 200 pounds. Bodarc is flat out heavy. Not in bad condition for 115+ years in the ground. It is still solid as a rock. It’s difficult to drive a deck screw into this wood.

Here's one shown for size.

Here’s one shown for size.

Next we built a beam to go across the 20ish foot front section of the porch. This will hold all the column weight.

Big-ass beam.

Big-ass beam (that’s a technical term)

Next we positioned the piers and filled them with concrete. Yes, I know in this pic the middle one looks off-level. It is not. That’s a frame of reference thing with the gas pipe and the temporary pier.

Piers set and filled with concrete.

Piers set and filled with concrete.

No, I don’t have to go down six feet here (or even one).

Some of the framing under the Old Vic…the porch mess not withstanding, this is some gorgeous work. 115+ years old and not a split, sag, sign of rot, etc…

Some of the framing under the house.

Some of the framing under the house.

All my structural issues will be around the edges…particularly the front/porch thing…as the box gutters (which are long gone) they liked to use in this era were…to put it mildly…problematic.

Oh, and a trip to the dump with a truckload full of rotten wood netted me…a new door!

“Ya never know when ya might need one” seems to be a common affliction of the old house owner…This house came with about 12 extra doors…and none of them fit in the ONE spot where I’m actually missing a door…

But I couldn’t let it lie…it’s not rotten, (just dirty) no significant dings, no splits or cracks, and it even has the hardware on it. When I finally figure out what doors I DON’T need…I’ll clean ’em up and put ’em up for sale. They tend to fetch a reasonable sum.

Hey, free door!

Hey, free door!

The “big-ass beam” is now in place and perfectly level (as well as plumb with the porch header) so the framing *should* go faster next week. With any luck, we’ll get some flooring down! (not sure, we’ve got to stain it on all sides before application!)

More next week!

CUAgain,
Daniel Meyer
